產品特色
- Dual Socket E2 (LGA-4710)
Supports Intel® Xeon® 6700E-series processors - 32 DIMMs up to 8TB 3DS ECC DDR5-6400: RDIMM
- Up to 12 Expansion slots, support PCIe 5.0 x16
- Supports up to 10 600W dual-width GPUs
- Support SAS/SATA/NVMe drives, support hot-swap
- 2 OCP 3.0 Slots
- AST2600, support IPMI 2.0
產品亮點
前視圖
➊ Power Button
➋ UID Button
➌ 2x USB2.0 Type A
➍ VGA
後視圖
➊ PSU
➋ UART（Type C port）
➌ 2x USB3.0 Type A
➍ RJ45（NC-SI）
➎ UID
➏ VGA
➐ PSU
主機板
➊ Intel® 6th Gen Xeon® SP
➋ 2x M.2 NVMe
➌ DC-SCM
➍ PSU
➎ 12x MCIO 8i
➏ 32x DIMM Slots for DDR5 memory
➐ 8x MCIO 8i
頂視圖
➊ Storage Module Supports 12LFF or 25SFF
➋ Support Intel 6th XEON SP
➌ 12 PCIeG5 x16 FHFL Slots, Up to 10 double-width GPU(s)
➍ DC-SCM AST2600 BMC
➎ 3+1 CRPS
➏ 2x PCIeG5 Switch
➐ 32 DDR5 RDIMM Slots
❽12x System Fans Module 6056
產品規格
| System Model | B4612-G6 |
|---|---|
| Processor | Intel® Xeon® 6700/6500 series processors(SRF-SP/GNR-SP) Up to 144 Cores, supports up to 350W TDP CPUs |
| Chipset | System on Chip |
| PCIe Expansion | Switch：2/1x Broadcom PEX89104, 104-lanes PCIeG5 Switch or direct link to CPU
Input：10/8 MCIO (PCIe5.0 x8) Output：12 FHHL PCIe 5.0 x16 slots |
| GPU Card | Up to 10 double-width or 12 single-width GPUs |
| Memory | 32 DDR5 memory slots, supporting DDR5 RDIMM 4400/4800/5600/6400MHz memory |
| Storage | Front hot-swap: Support 12 hot-swap 3.5/2.5 SAS/SATA hard drives
Internal M.2: 2 x M.2 (Up to 2280) SSD |
| Raid | Support to VROC，RAID 0, 1, 5, 6, 10, 50, and 60，Support Cache SuperCapacitor |
| Network | 1x 1GbE (RJ45) onboard, Support NCSI function 1x OCP3.0 slot |
| IO Ports | Front: 2x USB2.0, 1x VGA(option)
Rear: 2x USB3.0, 1x VGA，1x 1GbE (RJ45) ,1x USB TypeC（UART） Internal: 1 x TPM header |
| Fan | Standard 12 hot-swap N+1 redundant fans, supporting 6038/6056 specifications |
| Power Supply | 3+1 or 2+2 redundancy (2000W/2200W/2600W/3200W) |
| BMC | DC-SCM 2.0 module, Based Aspeed AST2600，support IPMI2.0/Redfish |
| Server Size | 175mm(H) x 437mm(W) x 842mm(D) |
| Operating Environment |
Operation Temperature.: 10° C ~ 35° C ,Non-Operation Temperature:-40° C~70° C
In/Non-operating Humidity: 20~90% (non-condensing) |
