Feature
- Various top cover with Kensington lock support.
- Standard Components - supports Mini-ITX motherboards and DC-ATX PSU
- Space for 1 2.5" HDD, maximum CPU cooler high to 25mm
- Optional stylish mesh cover for 2.5" HDD/SSD(Iso type)
- Meet CE/EMI standard, meet TAC2.0 thermal advantage
- Rigid structure for thermal and EMI considerations
- Easy space for system assembly and cable routing
Special Design
Multiple HDD installation layout
Iso type
Side type
Corner type
To adapt the variant CPU layout of mini ITX motherboards, the C20 series implement 3 most common HDD lay out to avoid the interference between CPU and HDD.
Options
Optional plastic stand and VESA mount kit for different application
Specifications
| Model | YY-C203 |
|---|---|
| Dimension WxHxD | 55 x 200 x 200 mm |
| M/B Form Factor | MINI-ITX M/B |
| Max. CPU Cooler Height | 25mm |
| HDD Bay | 1 x 2.5" HDD/SDD bay |
| FPIO | USB2.0x2+Audio Ports (USB3.1 Gen1 optional) |
| Cooling Fan (optional) | 1 x 4cm |
| Material | SGCC sheet metal T0.6mm |
| Power Supply (optional) | DC-ATX PSU GM-120W/12V DC Adapter 60W |
| Color | Black |
| Packing Carton Size | 13.6x22.6x28.8cm |
| MOQ | 500 pcs |
