Feature
- Maximum 4 port USB support
- Wide routing space
- Individual 2.5” SSD slot
- Complete EMI shielding
Complete storage device support
Easy assembling design
Special Design
- ❶ Top mount PSU
- ❷ 4 standard PCIE slot
- ❸ Wide routing space
- ❹ 5.25” ODD slot & floppy slot
- ❺ 3.5” HDD slot
- ❻ SSD mount rack
- ❼ Front 8cm fan site
- ❽ Rear 8cm fan site
- ➒ PCIE bracket
Specifications
| Module | YY-3803 |
|---|---|
| Case dimension | 173mm W x 405mm D x 365mm H |
| Motherboard configuration | micro ATX, mini ITX |
| Drive configuration | 2 - 5.25" ODD bay 1 - 3.5" Exposed bay 2 - 3.5" HDD bay 1 - 2.5" HDD bay |
| Optional system cooling fans | 1*8cm Fan for rear-mounted 1*8cm for front-mounted |
| Expansion slots and ports | Standard PCI 4 slots |
| Front panel control | Power switch, reset switch, Power LED, HDD LED USB 2.0 ( USB 3.1 gen 1 Option )/ Audio |
| Materials | Recyclable, RoHS compliant ABS front panel, SGCC Chassis |
| Emissions | Designed to meet FCC class |
| Color | Black |
| Power Supply | ATX12V 300W-550W PFC, 80+, Bronze, Silver, Gold |
| Packing /Shipping | packing without pallet: 745pcs/20' 1530pcs/40' 1790pcs/40'HQ packing on pallet: 520pcs/20' 1144pcs/40' 1320pcs/40'HQ |
